10m Clear Span White PVC Cover Aluminium Frame Outdoor Tents For
Parties / Conferences / Trade Shows
Description:
It's a very economical and elegant A shape tent, which often used
for outdoor exhibition, trade show, wedding, party and many other
events. The clear span of this type tent is from 3m to 40m and the
length is no limited which can fit different requirements. With no
pole inside, it’s 100% used for the events. Easy to be assembled
and dismantled. It's the most suitable tent type for your tent
rental business and event business. Also our tent can have
customized printing logo on the roofing and sidewalls, which is
impressed every guest.
UNIVERSAL TENT is an experienced tent supplier with creative and
delicate solution in tent field. We focus on global PVC tents
market and requirements and supply satisfactory and customized
solution to our customers.
Specification
Frame struss: hard pressed extruded aluminium 6061/T6(15HW) which can last more
than 20 years.
Fabric cover: high quality double PVC-coated polyester textile, 100% waterproof,
flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear
resistant, self-cleaning ability, etc.
Connector: strong hot-dip galvanized steel
Allowed temperature condition: -30 degree Celsius~+70 degree Celsius
Wind load: 70-100km/h (can be reinforced)
Snow load: 75kg/sqm (snow can't stay if use big degree roof pitch design)
Easy to be assembled and dismantled, movable.
No pole inside, 100% available interior space.
Materials
Fabric: Double PVC coated polyester fabric, 750-900g/sq. M, water
proof, UV resistance, fire retardant according to standard NFPA701,
CFM & DIN4102 B1/M2
Frame: Hard pressed extruded aluminum 6061/T6, anodized surface
finishing.
Connections: Hot-DIP galvanized
Superiority of tents
1. Sizes can be customized
2. Allowed temperature condition: -30 degree Celsius~+70 degree
Celsius
3. No pole inside, 100% room is available
4. Trouble-free and easy transportation, erection, dismantling,
storage
5. Wind loading up from 80 to 100 km per hour
6. Multifunctional, widely used for different request
Size of our Tent:
The clear-span of tent is from 3m to 40m, the length could be 6m,
9m, 12m, +3m more or 10m, 15m, 20m, and +5m more. And the length of
our tent is no limited. Customized size can also be available.
Applications:
Widely used for parties, weddings, events, celebrations, sports,
trade shows, warehouse, Hajj, conferences, cafe shops, restaurants,
corporate events, etc.
Optional Accessories
Covers: colourful cover, transparent cover, inflatable roof cover
Windows: dome or square clear PVC windows, mesh window, glass window for
glass wall
Wooden Flooring System: VIP cassette flooring, simple cassette flooring
Doors: double-wing glass door, single-wing glass door, glass fire door,
aluminium door, rolling shutter(automatic or manual)
Wall: soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel
wall, steel plate wall
Fixing Methods: ground anchors, weight plate, expandable bolts
Rain Gutters:inner roof beam rain gutter or rain gutter between two similar
tents
Other Optional Items: table, chair, lighting, AC, carpet, installation tools etc.
